Carel pCO1 series Application Program

Standard air-conditioning units
Carel Cod. +030221421 – Rel. 1.2 – April, 11, 2003
16
6.0 LIST OF PARAMETERS AND DEFAULT VALUES
The table below lists the parameters in the program, together with the following information: screen code (the screen code is displayed at the top
right) to assist the identification of the parameter, the default value, the minimum and maximum limits (range), and the unit of measure.
To find a specific parameter on the display, proceed as follows:
• Identify the parameter in the table below and the corresponding screen code
• Using the list of the screens (following paragraph) and the screen code, access the screen on the terminal
PARAMETER DESCRIPTION SCREEN DEFAULT USER
VALUE
RANGE UOM
Select display language A0 English En,It,Fr,De,Sp
Manual humidifier drain with unit ON A4 No No-Yes
Enter password A6 1234 0-9999
Modify outlet fan operating hours A7 0 0-99 . 0-999 hours
Modify compressor 1 operating hours A7 0 0-99 . 0-999 hours
Modify compressor 2 operating hours A7 0 0-99 . 0-999 hours
Device operating hour threshold A8 99 0-99 hours x 1000
Humidity probe calibration A9 0 -9.9 - 9.9 %RH
Condenser 1 pressure probe calibration A9 0 -9.9 - 9.9 bar
Condenser 2 pressure probe calibration A9 0 -9.9 - 9.9 bar
Ambient temperature probe calibration Aa 0 -9.9 - 9.9 ºC / ºF
Outside temperature probe calibration Aa 0 -9.9 - 9.9 ºC / ºF
Outlet temperature probe calibration Aa 0 -9.9 - 9.9 ºC / ºF
Recovery temperature probe calibration Ab 0 -9.9 - 9.9 ºC / ºF
Condenser 1 temperature probe calibration Ab 0 -9.9 - 9.9 ºC / ºF
Condenser 2 temperature probe calibration Ab 0 -9.9 - 9.9 ºC / ºF
Manual activation of digital outputs 1 – 2 – 3 Ac Off Off-on
Manual activation of digital outputs 4 – 5 – 6 Ad Off Off-on
Manual activation of digital outputs 7 – 8 Ae Off Off-on
Manual activation of digital outputs 9 – 10 Af Off Off-on
Manual activation of modulating outputs 1 – 2 Ag 0 0-10.0 Volt
Manual activation of modulating outputs 3 – 4 Ah 0 0-10.0 Volt
Manual activation of pre wash built-in humidifier Ai No No-Yes
Manual activation of total water drain built-in humidifier. Ai No No-Yes
Driver 1 valve control mode Aj Automatic Auto-Man.
Driver 1 valve manual opening steps Aj 0 0-9999 Steps
Driver 2 valve control mode Ak Automatic Auto-Man.
Driver 2 valve manual opening steps Ak 0 0-9999 Steps
Driver 1 manual release on start-up Al No No-Yes
Driver 2 manual release on start-up Am No No-Yes
Enter new Maintenance password An 1234 0-9999
Cyclical print interval H1 24 0-999 hours
Send immediate print H1 No No-Yes
Hour setting K0 current hour 0-23 Hours
Minute setting K0 current minutes 0-59 minutes
Day setting K0 current day 1-31
Month setting K0 current month 1-12
Year setting K0 current year 0-99
Enter Clock password K1 1234 0-9999
Enable temperature / humidity / On-Off time bands K2 No No-Yes
Start and end hour for On-Off time bands F1-1 and F1-2 K3 9 / 13 / 14 / 21 0-23 hours
Start and end minutes for On-Off time bands F1-1 and F1-2 K3 0 / 0 / 0 / 0 0-59 minutes
Start and end hour for On-Off time band F2 K4 14 / 21 0-23 hours
Start and end minutes for On-Off time band F2 K4 0 / 0 0-59 minutes
Select On-Off time bands (F1,F2,F3,F4) for each day K5 F2 F1-F4
Start hour temperature bands 1 and 2 K6 0 / 6 0-23 hours
Start minutes temperature bands 1 and 2 K6 0 / 0 0-59 minutes
Set point temperature bands 1 and 2 K6 23.0 see P1 ºC / ºF
Start hour temperature bands 3 and 4 K7 12 / 18 0-23 hours
Start minutes temperature bands 3 and 4 K7 0 / 0 0-59 minutes
