8.0 SCREENS
The screens are divided into five categories:
• USER screens not protected by password: present in all branches but “prog” and “menu+prog”, they show probes values, alarms, devices
working hours, hour and date; these screens also allow setting the temperature and humidity set points and regulating the clock. In the
following parameters table, they are indicated with symbol “!”.
• USER screens protected by password (1234, modifiable): these screens are accessed by pushing button “prog” and allow setting the main
functions (timing, sets, differentials) of the connected devices; the screens referring to non-available functions are not displayed. In the
following parameters table, they are indicated with symbol “"”.
• SERVICE screens protected by password (1234, modifiable): these screens are accessed by pushing button “maintenance” and allow
checking the devices periodically, calibrating the connected probes, modifying the working hours and managing the devices manually. In
the following parameters table, they are indicated with symbol “#”.
• CLOCK screens protected by password (1234, modifiable): these screens are accessed by pushing button “clock” and allow setting and
enabling the temperature and humidity time bands. In the following parameters table, they are indicated with symbol “$”.
• MANUFACTURER screens protected by password (1234, modifiable): these screens are accessed by pushing buttons “menu+prog” and
allow configuring the air-conditioning unit, enabling the main functions and selecting the connected devices. In the following parameters
table, they are indicated with symbol “%”.
8.1 LIST OF THE SCREENS
The following list indicates the displayed screens. Columns represent the screens loops: the first screen (A0, B0…) can be displayed by pushing
the relevant button and the other screens can be scrolled by using the arrow buttons. Codes (Ax, Bx, Cx…) are displayed in the screens upper
right corner, so as to be easily identified. The meaning of symbols !, "… is explained in the previous paragraph. Symbol PSW indicates the
screens for entering passwords.
+
" M0 " A0 " H0 " I0 " K0 " S0 PSW P0 PSW Z0
" M1 " A1 " H1 " I1 PSW K1 " S1 # P1 $ Z1
" M2 " A2 " I2 % K2 # P2
CONFIGURATION →
$ C0
" A3 " I3 % K3 # P3 $ C1
" A4 " I4 % K4 # P4 $ C2
" A5 " I5 % K5 # P5 $ C3
PSW A6 " I6 % K6 # P6 $ C4
& A7 " I7 % K7 # P7 $ C5
& A8 " I8 % K8 # P8 $ C6
& A9 " I9 % K9 # P9 $ C7
& Aa " Ia % Ka # Pa $ C8
& Ab " Ib # Pb $ C9
& Ac " Ic # Pc $ Ca
& Ad " Id # Pd $ Cb
& Ae " Ie # Pe $ Cc
& Af " If # Pf $ Cd
& Ag " Ig # Pg $ Ce
& Ah " Ih # Ph $ Cf
& Ai " Ii # Pi $ Cg
& Aj " Ij # Pj $ Cj
& Ak " Ik $ Ci
& Al " Il $ Cl
& Am " Im $ Cm
& An " In $ Cn
" Io $ Co
" Ip $ Cp
" Iq $ Co
" Ir $ Cp
" Is
PARAMETERS →
$ G0
" It $ G1
" Iu $ G2
" Iv $ G3
$ G4
$ G5
$ G6
$ G7
$ G8
$ G9
$ Ga
$ Gb
$ Gc
$ Gd
$ Ge
$ Gf
$ Gg
$ Gh
$ Gi
