248
APPENDIX
The camera has lamps: an Operation Lamp and an AF assist/
self-timer Lamp. These lamps light and flash to indicate the
current operational status of the camera.
* There are three lamp flash patterns. Pattern 1 flashes once
per second, Pattern 2 flashes twice per second, and Pattern 3
flashes four times per second. The table below explains what
each flash pattern indicates.
■ REC Mode
Indicator Lamps
Operation Lamp AF assist/self-timer Lamp
Operation Lamp
AF
Assist/
Self-timer
Lamp
Meaning
Green Red Amber Red
Lit
Operational (Power
on, recording enabled)
Pattern
3
Flash is charging.
Lit
Flash charging is
complete.
Lit
Auto Focus operation
was successful.
Pattern
3
Cannot Auto Focus.
Lit
LCD is off or in sleep
state.
Pattern
2
Image is being stored.
Pattern
1
Storing movie or
processing image.
Pattern 1
Self-timer countdown
(10 - 3)
Pattern 2
Self-timer countdown
(3 - 0)
