Configuring Settings (Tutorial)
EN-81
This section explains reverb type, chorus type, and delay time settings. For information about other effect settings,
see the Digital Keyboard’s USER’S GUIDE (Basics).
1.
On the MENU screen, touch “EFFECT”.
This displays the EFFECT screen.
2.
Touch a setting item and then configure the settings described below.
EFFECT Screen Reverb Effect Settings
Item Description Setting
Reverb Edit
Reverb Type Selects the reverb type. Small Room, Room 1, Room 2,
Room 3, Large Room 1, Large Room 2,
Hall 1, Hall 2, Hall 3, Stadium 1,
Stadium 2, Plate 1, Plate 2, Plate 3,
Short Delay, Delay, Long Delay 1,
Long Delay 2, Pan Delay,
Long Pan Delay
Time Adjusts the reverb time. 0 to 127
Early Reflection Adjusts the level of the initial reflection. 0 to 127
High Damp Adjusts the high-range damp. A smaller number increases
damping.
0 to 127
Tone Adjusts the tone. 0 to 127
Return Adjusts the return level. 0 to 127
Chorus Edit
Chorus Type Selects the chorus type. Parameters whose settings can be
configured depend on the selected chorus type.
Chorus types
Chorus 1, Chorus 2, Chorus 3,
Chorus 4, FB Chorus, Flanger 1,
Flanger 2, Flanger 3, Flanger 4,
Short Delay 1, Short Delay 2,
Short Delay 3, Short Delay 4,
Soft Chorus, Bright Chorus,
Deep Chorus
Phaser Types
Phaser 1, Phaser 2, Slight Phaser,
Deep Phaser, Slow Phaser, Fast Phaser,
Reso Phaser, Random Phaser 1,
Random Phaser 2
LFO Rate Adjusts the LFO rate.*
1
0 to 127
LFO Depth Adjusts the LFO depth.*
1
0 to 127
Feedback Adjusts the feedback amount.*
1
0 to 127
Tone Adjusts the tone.*
1
0 to 127
Delay Time Adjusts the delay time.*
1
0 to 127
Resonance Adjusts the strength of resonance.*
2
0 to 127
To Next Page
