Digital Piano Operations
EN-12
You can use the lower range of the keyboard to sound a bass
tone. When the keyboard is split between a left side and a
right side range, the tone assigned to the lower (left side)
range is the “Lower part tone”, which is referred to as the
“Lower tone” in this manual. The tone assigned to the upper
(right side) range is the “Upper1 part tone”, which is referred
to as the “Upper1 tone”.
Any one of the 17 non-bass tones can be assigned to the
upper range.
■ To use split to play bass notes in the lower range
1.
Use the procedure under “Selecting a Single
Tone” (page EN-10) to select the upper range
(Upper1) tone.
2.
While holding down 9 ELEC. PIANO, press
the D2 keyboard key.
This assigns the bass tone to the lower range.
3.
Release 9 ELEC. PIANO.
• You can adjust the volume of the Lower part and configure
other Lower part settings. For more information, see
“Configuring Upper2 Part and Lower Part Settings” (page
EN-30).
■ To unsplit the keyboard
You can perform either of the operations below to unsplit the
keyboard.
• While holding down 9 ELEC. PIANO, press a keyboard
key from A0 through C{2. This unsplits the keyboard and
makes the tone assigned to the keyboard key you press
become the Upper2 tone (page EN-11).
•Touch 8 GRAND PIANO or 9 ELEC. PIANO.
This unsplits the keyboard and selects the tone that
corresponds to the button you touched.
Touch Response alters tone volume in accordance with
keyboard pressure (speed). This provides you some of the
same expressivity you get on an acoustic piano.
Splitting the Keyboard Between Two Tones
Split Point
High RangeLow Range
Changing Keyboard Response to
Touch Pressure (Touch Response)
Pressing fast produces
louder notes.
Pressing slowly
produces softer notes.
Do not try to use too
much pressure.
To Next Page
