R-15
QT-6600 Reference Manual
1-6. Input/output connectors
Power switch
Main power switch is located in the power switch cover.
Input /output connectors
Inline connector, COM port, and drawer cable are located in the bottom side connector
cover.
DISPLAY
SCANNER
PC/MODEM
COM3
COM6
COM2
COM5
COM1
COM4
SPK
PS/2
KEYBOARD
MIC
LAN
Brightness COM3 COM6 COM2 COM5 COM1 COM4
Inline (10/100Base-T)
PS/2 Keyboard
AC Adaptor
Drawer 2
Drawer 1
Ext. microphone
Ext. speaker
Bottom side of the terminal
Power switch
