— 22 —
5-5-2. LCD VGA Ports
Pin J9 - Color LCD Display J10 - Monochr. LCD Display
1 DL4 - Display Data Signal Scan Start-up Signal
2 Gnd Input Data Latch
3 DL5 Data Input Clock
4 Scan Start-up Signal +5V
5 DL6 +5V
6 Input Data Latch Gnd
7 DL7 VEE - Power supply for LCD
8 Gnd DU0
9 Gnd DU1
10 Data Input Clock DU2
11 DL0 DU3
12 Contrast Adjust Voltage DL0
13 DL1 DL1
14 +5V DL2
15 Gnd DL3
16 +5V
17 DL2
18 +5V
19 DL3
20 Gnd
21 DU3 - Display Data Signal
22 DU4
23 DU2
24 DU5
25 DU1
26 Gnd
27 DU0
28 DU6
29 Gnd
30 DU7
[LCD Ports]
