Casio SE-S100 Service Manual

SE-S100 / PCR-T285 / PCR-T295
– 22 –
5-3. Test Item
This diagnostic program tests the following items.
No. Item Command
1 Status Display –
2
Batch Test 1
(RAM / printer/ time setting / buzzer / drawer)
1
3 Batch Test 2 (main display, customer display)
2
Memory Test
4 RAM Test (write / read)
n
0 1 1
5 Flash ROM Test (clear / write / read)
n
3 1 2
6 SD Card Test (write / read, report)
n
0 1 4
(write / read)
n
6 1 4
(report)
Display Test
7 Display Test (main, customer)
n
0 2 1
(Main)
n
0 2 2
(Customer)
8 Main Display Backlight Test
c
0 1 2 1
9 Main Display Contrast Adjustment
4 2 1
Printer Test
10 Internal Printer Character Print Test
a c n
0 3 3
Other Test
11 Time & Date Setting / Time & Date Display
h h
m m s s
0 0 7 0
(Time Setting)
y y
m m
d d
0 1 7 0
(Date Setting)
0 7 0
or
1 7 0
(Time and Date Display)
12 Drawer Open Test
n
0 9 1
13 Buzzer Test
n
0 9 2
14 Key Test
9 4

Casio SE-S100 Specifications

General

Types of payment	Cash
Number of clerks/departments	24
Number of Price Look-Up codes (PLUs)	2000 PLUs
Power source	AC
AC input voltage	100-240 V
Supported paper width	58 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Backlight	Yes
Display digits	10 digits
Second display type	LCD
Display number of lines	2 lines
Display number of characters	20

Weight and Dimensions

Depth	345 mm
Width	326 mm
Height	167 mm
Weight	3300 g
