Casio SE-S100 Service Manual

SE-S100 / PCR-T285 / PCR-T295
– 28 –
[8] Main Display Backlight Test
[Function]
Tests the Main Display backlight.
[Operation]
Command :
c
0 1 2 1
o
c: Backlight ON/OFF
0

Backlight “OFF”

Backlight “ON” with any key
1 Backlight “OFF"
2 Backlight “ON"
[Printout of the result]
DISP c0121
BACK LIGHT OK
END c0121
[9] Main Display Contrast Adjustment
[Function]
Adjusts the LCD contrast for the Main Display and writes the adjustment value to the FLASH ROM.
Up to 16 adjustments can be written to the Flash ROM. If more than 16 adjustments are written, an
error occurs.
[Operation]
Command :
4 2 1
o
Use the keys below to adjust the LCD contrast, and press
F
to writes the adjustment value to
the Flash ROM.
Contrast +1 (Dark) Contrast –1 (Light)
[PAPER SAVING] [POST RECEIPT]
[Display]
LCD contrast value
[Printout of the result]
DISP 421
LCD CONTRAST xx
END 421

LCD contrast value
[Important]
If more than 16 adjustments are written, an error occurs. In such cases, perform the following
command to clear the data.
Command :
1 0 4 2 1
o

Casio SE-S100 Specifications

General

Types of payment	Cash
Number of clerks/departments	24
Number of Price Look-Up codes (PLUs)	2000 PLUs
Power source	AC
AC input voltage	100-240 V
Supported paper width	58 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Backlight	Yes
Display digits	10 digits
Second display type	LCD
Display number of lines	2 lines
Display number of characters	20

Weight and Dimensions

Depth	345 mm
Width	326 mm
Height	167 mm
Weight	3300 g
