Casio SE-S100 Service Manual

SE-S100 / PCR-T285 / PCR-T295
– 3 –
3. INITIALIZATION
Important:
Main PCB (E261-1 PCB) supplied as spare parts have been pre-installed application and diagnostic
software without LOCALE code.
Then LOCALE code should be set at fi rst when you replace a main PCB from spare parts in your stock.
Initial LOCALE judgment/settings
Does LOCALE information exist ?
Yes
No
Yes
Does LOCALE information exist ?
No
Does Flash ROM information exist ?
Yes
No
Set the Mode switch to the position other than [OFF].
Set LOCALE code.
Command: d1 d2
0016
o
Unplug from AC outlet.
Wait 10 sec., then plug into AC outlet.
( Restore INIT )
End
After IPL is completed.
Go to the setting procedure by destination.
10
20
30
50
60
EU
US
UK
CANADA
Other areas
d1 d2: LOCALE code
Diagnostic program mode
Remove the memory protection batteries from battery compartment and unplug the power cord
from AC outlet.
After 10sec. or more, set the memory protection batteries into battery compartment and plug the
power cord into AC outlet.
Tips:
Regarding to deletion of the LOCALE information
In diagnostic program mode, input the following command.
2 1 6
o

Casio SE-S100 Specifications

General

Types of payment	Cash
Number of clerks/departments	24
Number of Price Look-Up codes (PLUs)	2000 PLUs
Power source	AC
AC input voltage	100-240 V
Supported paper width	58 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Backlight	Yes
Display digits	10 digits
Second display type	LCD
Display number of lines	2 lines
Display number of characters	20

Weight and Dimensions

Depth	345 mm
Width	326 mm
Height	167 mm
Weight	3300 g
