Casio SE-S100 Service Manual

SE-S100 / PCR-T285 / PCR-T295
– 37 –
7-2. Parts List
S-type Drawer
1: SE-S100SB_BK
2: SE-S100SB_GD
3: SE-S100SB_RD
4: SE-S100SB_SR
5: SE-S100SC_GD
6: SE-S100SC_RD
7: SE-S100SC_SR
8: SE-S100SG_BK
9: SE-S100SG_GD
10: SE-S100SG_RD
11: SE-S100SG_SR
12: SE-S100SK_BK
13: SE-S100SK_GD
14: SE-S100SK_RD
15: SE-S100SK_SR
16: PCR-T285_BK
17: PCR-T295_BK
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
FINAL-ASSY
N 1 10500428 COVER/PRINTER/GD RJE504003-006V01 1 1 1 1 C
N 1 10500427 COVER/PRINTER/SR RJE504003-005V01 1 1 1 1 C
N 1 10500426 COVER/PRINTER/RD RJE504003-004V01 1 1 1 1 C
N 1 10500425 COVER/PRINTER/BK RJE504003-003V01 1 1 1 1 1 C
2 10349665 PULLY/WIND RJE501880-001V04 11111111111111111C
3 10445632 SPOOL/PAPER RJE504072-001V01 11111111111111111C
4 10445436 COVER/BATTERY RJE504019-001V01 11111111111111111C
N 5 10254924 SUB ASSY/KEY SET RJE500074*002V03 11111111111111111C
N 6 10500440 COVER/SD RJE504387-001V01 11111111111111111C
N 7 10271807 HOLD/ROM RJE502216-001V01 11111111111111111C
N 8 10500821 COVER/PCB RJE504396-001V01 11111111111111111C
8-1 Cloth tape/19x45 W19XL45 22222222222222222X
8-2 Cloth tape/19x25 W19XL25 11111111111111111X
9 10445450 COVER/CORD RJE504013-001V01 11111111111111111C
10 10233584 SEPARATER/BILL RJE500103-001V02 1111 C
S1 Screw (3x5) S-BDST-3X5Z3 22222222222222222X
S2 Screw (3x16) S-PAPT-3X16Z3 22222222222222222X
S3 Screw (3x8) S-BDPT-3X8Z3 11111111111111111X
S5 Screw (3x6, washer) S-PASEMA-3X6Z3 22222222222222222X
RN Item Code No. Parts Name Specification
Q'T
Y

Casio SE-S100 Specifications

General

Types of payment	Cash
Number of clerks/departments	24
Number of Price Look-Up codes (PLUs)	2000 PLUs
Power source	AC
AC input voltage	100-240 V
Supported paper width	58 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Backlight	Yes
Display digits	10 digits
Second display type	LCD
Display number of lines	2 lines
Display number of characters	20

Weight and Dimensions

Depth	345 mm
Width	326 mm
Height	167 mm
Weight	3300 g
