Casio SE-S100 Service Manual

SE-S100 / PCR-T285 / PCR-T295
– 1 –
1. SPECIFICATIONS
1-1. Electrical Specifi cations
Power Consumption
In operation Max.
120 V 230 V 240 V
360 mA 240 mA 240 mA
Mode off Max. 30 mA 40 mA 40 mA
Memory protection Back-up battery
Back-up period
Battery life
Mangan Battery (UM-3×2 pcs)
1 year (25 °C)
Replace the battery every 1 years.
Clock & Calendar Accuracy
Auto calendar
Within ± 40 sec. per month (25 °C)
Effective until 2099 A.D.
1-2. Environmental Specifi cations
Operating temperature 0 °C ~ 40 °C
Operating humidity 10 % ~ 90 %
Storage temperature -25 °C ~ 65 °C
Storage humidity 10 % ~ 95 %
Vibration strength Durable when one side of the unit is lifted to a height of 3 cm and dropped.
1-3. Printer Specifi cations
Name FTP-628MCL518
Method Thermal line dot printing
Dots/line 384 dots/line
Dot pitch Length 8 dots/mm, wide 8 dots/mm
Paper roll 58 mm × 80 mm φ (Max.)
1-4. Option List
Name Model Note
Waterproof Cover WT-93
1-5. Drawer List
Type Model Specifi cation
S DL-1335A D-27L2C-D54RM-4
S DL-1844A D-27L2C-D53RM-4
M DL-2816A D-25L2C-B84RM-4

Casio SE-S100 Specifications

General

Types of payment	Cash
Number of clerks/departments	24
Number of Price Look-Up codes (PLUs)	2000 PLUs
Power source	AC
AC input voltage	100-240 V
Supported paper width	58 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Backlight	Yes
Display digits	10 digits
Second display type	LCD
Display number of lines	2 lines
Display number of characters	20

Weight and Dimensions

Depth	345 mm
Width	326 mm
Height	167 mm
Weight	3300 g
