Instrument Panel
59
Passenger Side Air Bag
Indicator Lamp
PAB
When the ignition switch is turned on,
this lamp will light to remind the driver
to notice the switch position of the
passenger side air bag. If the passenger
side air bag switch is at ON position,
then this lamp will turn off within 4-5 s
after the ignition switch is turned on. If
the passenger side air bag is at OFF
position, then this lamp will keep lighting
after the ignition switch is turned on.
Fuel Gauge
Standard fuel tank capacity: 61 L
When the pointer reached the fuel empty
position “E” (as pointed by the arrow),
the fuel tank has approximate 10 L fuel.
The pointer will move from full position
“F” after the vehicle with fully filled fuel
drives for certain distance.
During the refuelling, the fuel volume
that capable of refuelling will be lower
than the nominal capacity since the fuel
tank has residue fuel.
If the low fuel lever alarm lamp lights,
please refill with fuel as soon as possible.
Refer to “Low Fuel Level Alarm Lamp”.
Speedometer
To indicate the current vehicle speed.
Notice:
The speedometer is affect by the tire size.
Please use Chery genuine size tires,
otherwise the speedometer will not
display the correct vehicle speed.
)
(
