Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Network Configuration Menu
4-14
Cisco Unified IP Phone 7906G and 7911G for Cisco Unified Communications Manager 6.0
OL11954-01
Related Topics
• Displaying a Configuration Menu, page 4-2
• Unlocking and Locking Options, page 4-4
• Editing the Values of an Option Setting, page 4-5
• Overview of Options Configurable from a Phone, page 4-6
PC Port
Configuration
(applies to 7911G
only)
Speed and duplex of the access port (labeled
10/100 PC). Valid values:
• Auto Negotiate
• 10 Half—10-BaseT/half duplex
• 10 Full—10-BaseT/full duplex
• 100 Half—100-BaseT/half duplex
• 100 Full—100-BaseT/full duplex
If the phone is connected to a switch,
configure the port on the switch to the same
speed/duplex as the phone, or configure both
to auto-negotiate.
If you change the setting of this option, you
must change the SW Port Configuration
option to the same setting.
1. Unlock network configuration
options.
2. Scroll to the PC Port
Configuration option and then
press the Edit softkey.
3. Scroll to the setting that you
want and then press the Select
softkey.
4. Press the Save softkey.
PC VLAN
(applies to 7911G
only)
Allows the phone to work better with
non-Cisco switches. Strips the 802.1P/Q tags
from the packets going to a PC from the
access port on the phone. The Admin. VLAN
ID must be set before you can change this
option.
1. Unlock network configuration
options.
2. Make sure the Admin. VLAN
ID option is set.
3. Scroll to the PC VLAN
option, press the Edit softkey,
and then enter a new PC
VLAN setting.
4. Press the Va lidate softkey and
then press the Save softkey.
Table 4-2 Network Configuration Menu Options (continued)
