Supported DIMM Upgrade
The Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router support the following DIMM upgrade:
DescriptionPID
The Cisco ASR 1001-HX Router has two DIMM slots and supports
8-GB configuration by default (two 4-GB DIMMS), and can be upgraded
to 16-GB (two 8-GB DIMMS) configuration.
M-ASR1001HX-16GB
The Cisco ASR 1002-HX Router has four DIMM slots and supports
16-GB configuration by default (two 8-GB DIMMS), and can be
upgraded to 32-GB (four 8-GB DIMMS) configuration.
M-ASR1002HX-32GB
Related Topics
Removing and Replacing a DIMM, on page 117
Power Supplies
The Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router support AC or DC power supply options.
The modular chassis configurations support the installation of two power supplies for redundancy. When an
external power supply fails or is removed, the other power supply provides power requirements for the chassis.
This allows you to hot-swap the power supply without impacting the functionality of the router.
A router can support two AC or two DC power supplies. Do not install mixed AC and DC power supply
units in the same chassis.
Caution
The power supplies used in Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router are different
and they should not be mixed or swapped. The size and structural dimensions are the same, therefore they
both look alike. It would be hazardous if you accidently inserted the wrong power supply into the PEM
slot.
Caution
The power supplies are used in a 1 + 1 redundant configuration. There is no input switch on the faceplate of
the power supplies. A power supply is switched from Standby to On by way of a system chassis power switch.
The following table lists the power supplies that you can order:
Power SupplyPart Number
Cisco ASR 1002-HX Router power supply module with plug-side intake
airflow, A/C, 750W, 85–264V
ASR1000X-AC-750W
Cisco ASR 1002-HX Router power supply module with plug-side intake
airflow, A/C, 750W, 85–264V, spare
ASR1000X-AC-750W=
Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router Hardware Installation Guide
20
Supported Hardware Components
Supported DIMM Upgrade
