Cisco ASR 903 Installation Guide

Ports on the OC-192 are numbered from 1 to 8.
• Ports 0 to 7 are multi-rate ports, that support OC-3, OC-12, OC-48, Fast Ethernet interfaces, and the 1
Gigabit Ethernet interfaces.
• Port 8 is the 10 Gigabit Ethernet port that supports the OC-192 interfaces.
Port Restrictions
• The SFP+ port configuration is supported only on OC-192 interfaces port. If this port is enabled, other
SFP ports cannot be used (see the table given in Port Combinations Usage Guidelines section).
• Each SFP port can be configured for SONET or Ethernet.
• SFP ports configuration parameter, (see the table given in Port Combinations Usage Guidelines section):
• Maximum of 4 x OC-48 interfaces are supported per interface module
• For each OC-48 port enabled, neighboring SFP ports cannot be configured
• OC-3 and OC-12 port configuration is supported on all ports simultaneously
• 1 Gigabit Ethernet port configuration is supported on all ports simultaneously
1 Gigabit Ethernet port configuration is not supported.
Note
• Seamless migration from SONET to 1 Gigabit Ethernet interfaces is supported on all SFP ports
Port Combinations Usage Guidelines
SFP+
Port
OrSFP+
Port
OrSFP+
Port
OrSFP+
Port
—SFP+
Port
8
—SFP+
Port
8
—SFP+
Port
8
OC-192SFP+
Port
8
1 GE7SPF
Port
OC-3
7SPF
Port
OC-487SPF
Port
—7SPF
Port
1 GE6OC-126—6—6
1 GE5OC-125OC-485—5
1 GE4OC-34—4—4
1 GE3OC-3
3OC-483—3
1 GE2OC-122—2—2
1 GE1OC-121OC-481—1
1 GE0OC-30—0—0
For information on supported SFP modules, see Cisco ASR 900 Series Aggregation Services Routers Data
Sheet.
For more information about installing an optical interface module, see Interface Module Installation.
Cisco ASR 903 and ASR 903U Aggregation Services Router Hardware Installation Guide
37
