2-21
Cisco ASR-920-24SZ-IM, ASR-920-24SZ-M, ASR-920-24TZ-M Aggregation Services Router Hardware Installation Guide
Chapter 2 Preparing for Installation
Receiving the Router
Tools and Equipment
You need the following tools and equipment to install and upgrade the router and its components:
• ESD-preventive cord and wrist strap
• Antistatic mat or antistatic foam
• Number 1 and Number 2 Phillips-head screwdrivers
• #12-24 pan-head screws to secure the router to the equipment rack
• Cables for connecting to the network ports (depending on the configuration)
Note For more information about cable specifications, see the Troubleshooting section.
• Ethernet hub, switch, or PC with a network interface card for connecting to the Ethernet ports
• Console terminal (an ASCII terminal or a PC running terminal emulation software) that is
configured for 9600 baud, 8 data bits, no parity, no flow control, and 1stop bit
• Console cable for connecting to the console port
• Ratcheting torque screwdriver with a Phillips head that exerts up to 30-pound force per square inch
(in-lb) or 0.02-kilograms force per square millimeter (kgf/mm2) of pressure
• Crimping tool as specified by the ground lug manufacturer
• Wire-stripping tools for stripping both 6-AWG and 14-AWG wires
• Tape measure and level
Warning
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Unpacking and Verifying the Shipped Contents
When you receive your chassis, perform the following steps:
Step 1 Inspect the box for any shipping damage. If there is obvious physical damage, contact your Cisco service
representative.
Step 2 Unpack the Cisco ASR 920-24SZ-IM, ASR-920-24SZ-M, ASR-920-24TZ-M Router.
Step 3 Perform a visual inspection of the chassis.
Step 4 Use Table 2-2 to check the contents of the Cisco ASR 920-24SZ-IM, ASR-920-24SZ-M,
ASR-920-24TZ-M Router shipping container. Do not discard the shipping container. You will need the
container if you move or ship the Cisco ASR 920-24SZ-IM, ASR-920-24SZ-M, ASR-920-24TZ-M
Router in the future.
