What to Do Next
Route the cable through the Supervisor PIC cable management bracket and chassis-mounted fiber/cable routing
guide.
Cable Management for the Supervisor PIC in the Cisco cBR Chassis
The following accessories are used for routing the cables connected to the Supervisor PIC:
•
Supervisor PIC cable management bracket
•
Chassis-mounted cable strap-down clips
•
Chassis-mounted snap-on plastic fiber/cable routing guides
Use the upper cable management bracket and fiber/cable routing guides for routing the cables connected to
the upper Supervisor PIC and the lower cable management bracket and fiber/cable routing guide for routing
the cables connected to the lower Supervisor PIC.
The strap-down clips have multiple uses. They can be used:
•
to strap down cable bundles or conduit (there are multiple tie down points on each strap-down clip)
•
as a base for two snap-on plastic fiber/cable routing guides
Before You Begin
•
Install the Supervisor PIC.
•
Install the Supervisor PIC cable management bracket.
• Install the chassis-mounted cable strap-down clips and attach the snap-on plastic fiber/cable routing
guides, as necessary based on the cable routing preference.
•
Connect the cables to the appropriate ports on the Supervisor PIC.
Required Tools and Equipment
•
Cable ties
Step 1
Perform the following for the fiber-optic cables connected to the Supervisor PIC:
•
If you are using a chassis-mounted snap-on plastic fiber/cable routing guide, route the fiber-optic cables through
the upper slot of the snap-on plastic fiber/cable routing guide and then through the upper slot of the Supervisor PIC
cable management bracket. Secure the cable bundle using cable ties.
•
If you are using a chassis-mounted cable strap-down clip without the snap-on plastic fiber/cable routing guide,
route the fiber-optic cables through the upper slot of the Supervisor PIC cable management bracket. Secure the
cable bundle to the upper tie down point on the strap-down clip using a cable tie.
Cisco Converged Broadband Routers Hardware Installation Guide
20
Installing the Supervisor in the Cisco cBR Chassis
Cable Management for the Supervisor PIC in the Cisco cBR Chassis
