Route the Supervisor PIC cables through the Supervisor PIC cable management bracket and
chassis-mounted fiber/cable routing guide.
Installing the SFP+ Modules in the Supervisor PIC
Before You Begin
Do not install or remove the SFP+ module with fiber-optic cables still attached to it. Doing so may damage
cables, cable connectors, or the optical interfaces and may interfere with the SFP+ module latching properly
into its socket connector. Disconnect all cables before removing or installing an SFP transceiver module.
Caution
•
Attach an ESD-preventive wrist strap to your wrist and connect the other end to the grounding lug
connected to the chassis.
•
You must use the supported SFP+ modules. The following SFP+ modules are supported on the Supervisor
PIC:
◦
SFP-10G-SR
◦
SFP-10G-LR
◦
SFP-10G-ER
◦
SFP-10G-ZR
◦
SFP-10G-LRM
Required Tools and Equipment
•
ESD-preventive wrist strap
•
SFP+ module
Step 1
Remove the SFP+ module from its protective packaging.
Cisco Converged Broadband Routers Hardware Installation Guide
43
Installing the Supervisor in the Cisco cBR Chassis
Installing the SFP+ Modules in the Supervisor PIC
