SSD (slot 1)4Twelve RJ-45 1G/100M/10M auto
duplex/auto MDI-X Base-T ports
Ethernet 1/1 through 1/12 labeled top to
bottom, left to right
3
System LEDs6Locator beacon5
RJ-45 console port8Type A USB 2.0 port7
4 fixed SFP (1G) ports
Fiber ports 1/13 through 1/16 labeled
left to right
10Pull-out label card9
SSD (slot 2)11
The following figure shows the front panel of the Firepower 2130 and 2140 security appliance. See Front
Panel LEDs, on page 9 for a description of the LEDs.
Figure 6: Firepower 2130 and 2140 Front Panel
Locator beacon2Power LED1
Twelve RJ-45 1G/100M/10M auto
duplex/auto MDI-X Base-T ports
Ethernet 1/1 through 1/12 labeled top
to bottom, left to right
4Gigabit Ethernet management port
Management 0 (also referred to as
Management 1/1 and Diagnostic 1/1)
3
SSD 26SSD 15
Type A USB 2.0 port8System LEDs7
Pull-out label card10RJ-45 console port9
Network Module (network module slot
1)
124 fixed SFP+ (1G/10G) ports
Fiber ports 13 through 16 labeled left to
right
11
Cisco Firepower 2100 Series Hardware Installation Guide
7
Overview
Front Panel
