Two-post grounding lug
The two-post grounding lug is
included in the accessory kit.
Note
9
Power Switch
The power switch is located to the left of power supply module 1 on the rear of the chassis. It is a toggle
switch that controls power to the system. If the power switch is in standby position, only the 3.3V
standby power is enabled from the power supply module and the 12V main power is OFF. When the
switch is in the ON position, the 12V main power is turned on and the system boots.
Before you move the power switch to the OFF position, use the shutdown commands so that the system
can perform a graceful shutdown. This may take several minutes to complete. After the graceful shutdown
is completed, the front panel power LED is unlit and the console displays Power Down. See the FXOS
Configuration Guide for more information on using these commands.
If you move the power switch to the OFF position before the shutdown
command sequence has completed or if you remove the system power cords
before the graceful shutdown is complete, disk corruption can occur.
Caution
For More Information
See Remove and Replace the Power Supply Module, on page 46 for the procedure for removing and
replacing the power supply module in the Firepower 2130 and 2140.
See Remove and Replace the Fan Tray, on page 54 for the procedure for removing and replacing the
fan tray in the Firepower 2130 and 2140.
See Ground the Chassis, on page 38 for the procedure for using the grounding lug to ground the chassis.
See Power Supply Modules, on page 17 for a description of the power supply module LEDs.
See Front Panel LEDs, on page 9 for a description of the fan LEDs.
Network Modules
The Firepower 2130 and 2140 contain one network module slot that provides optical or electrical network
interfaces. Network modules are optional, removable I/O modules that provide either additional ports or
different interface types. The Firepower network module plugs into the chassis on the front panel.
The network module is NOT hot swappable.Note
The Firepower 2130 and 2140 support the Firepower 8-port 10G Network Module single-wide
(FPR-NM-8X10G SFP+). The 10 Gigabit Ethernet network module ports are numbered from top to bottom,
left to right.
Cisco Firepower 2100 Series Hardware Installation Guide
15
Overview
Network Modules
