Cisco SF352-08MP Administration Guide

Multicast
IP Multicast Group Address
268 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
15
To configure and display the registration for the interfaces within the group, select an address,
and click Details.
The page displays:
• VLAN ID—The VLAN ID of the Multicast group.
• MAC Group Address—The MAC address of the group.
STEP 7 Select either port or LAG from the Filter: Interface Type menu.
STEP 8 Click Go to display the port or LAG membership of the VLAN.
STEP 9 Select the way that each interface is associated with the Multicast group:
• Static—Attaches the interface to the Multicast group as a static member.
• Dynamic—Indicates that the interface was added to the Multicast group as a result of
IGMP/MLD snooping.
• Forbidden—Specifies that this port is not allowed to join this Multicast group on this
VLAN.
• None—Specifies that the port is not currently a member of this Multicast group on this
VLAN.
STEP 10 Click Apply, and the Running Configuration file is updated.
NOTE Entries that created in the IP Multicast Group Address page cannot be deleted
in this page (even if they are selected).
IP Multicast Group Address
The IP Multicast Group Address page is similar to the MAC Group Address page except that
Multicast groups are identified by IP addresses.
The IP Multicast Group Address page enables querying and adding IP Multicast groups.
