Smart Network Application (SNA)

Topology View

468 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4

• D—Open the follow window:

This window displays or enables the following:

- Displays your Access Permissions

- Log out of system by clicking Log out.

- Upgrade your permissions by clicking Upgrade Permission.

• E—Click to delete a selected device.

Topology View

The topology view is the main view of the SNA.
