Cisco TelePresence SX20 Codec User Manual

D14949.13 SX20 Codec API Reference Guide TC7.3, OCTOBER 2015. Copyright © 2015 Cisco Systems, Inc. All rights reserved. 12
Cisco TelePresence SX20 Codec API Reference Guide
Using the command line
Help
To get a list of all supported root commands you can type ?
or help after connecting to the TelePresence System using
RS-232, Telnet or SSH.
Bye
Typing the bye command closes the command line interface.
?
- User Commands -
help xcommand xconfiguration xevent xfeedback
xgetxml xdocument xhistory xpreferences xstatus
bye echo log systemtools
OK
API commands
xConfiguration
Configurations are system settings, such as system name
and network settings. These are persistent across boots.
Refer to ”Configurations” on page 15.
xCommand
Commands instruct the codec to execute actions, such as to
dial a number or to search the phone book.
Refer to ”Commands” on page 14.
xStatus
A status contains the current state of the codec, such as
connected calls, the status of the gatekeeper registration,
connected inputs and output sources.
Refer to ”Status” on page 16.
xFeedback
The Feedback commands are used to specify what parts of
the configuration and status hierarchies to monitor. Feedback
is only issued on the Telnet or SSH session for which it is
specified. If you are connecting to the codec with multiple
sessions, you have to define feedback individually for each
session. Refer to ”Feedback mechanism” on page 19.
xPreferences
The xPreferences command is used to set preferences for
the RS-232, Telnet and SSH sessions.
Refer to ”API output” on page 11.
Echo <on/off>
If echo is set to On the key inputs are displayed when
entering text in a command line interface.
If echo is set to Off no user input is displayed when entering
text in a command line interface.
xEvent
the xEvent command returns information on which events are
available for feedback. Refer to ”Events” on page 17.
xHistory
The xHistory command returns the call log.
xGetxml
The xGetxml request returns an XML document based on the
location parameter attached to the request. The elements
(or a complete document) matching the expression will be
returned. Refer to ”Feedback mechanism” on page 19.
Other commands
Systemtools
The systemtools commands are used for administrative
control of the codec and are only available from the
command line interface. Systemtools are not a part of the
programming API.
Refer to ”The SystemTools commands” on page 215.
Log
The log command is used to enable advanced logs. It is only
used for debugging the system.
Command line shortcuts
If your client supports it, there are some timesaving shortcuts
you can use:
• Tab-completion to complete the commands and
arguments.
• Arrow up and arrow down keys to navigate your
command history.
• < C T R L- a > : Jump to the beginning of the line.
• < C T R L- e > : Jump to the end of the line.
• < C T R L- r > : Incremental command history search.
• < C T R L- w > : Erase the current line.
Contents
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus
About the API

Cisco TelePresence SX20 Codec Specifications

General

Max Frame Rate	60 fps
Video Outputs	2 x HDMI
Dual Stream	Yes
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Video Standards	H.261, H.263, H.263+, H.264
Audio Standards	G.711, G.722, G.722.1, G.729
Max Video Resolution	1920 x 1080
Network Protocols	H.323, SIP
Power Supply	100-240V AC, 50/60Hz
Video Inputs	1 x HDMI, 1 x DVI-I
Network Interface	10/100/1000 Ethernet
Operating Temperature	0°C to 35°C (32°F to 95°F)
Relative Humidity	10% to 90% (non-condensing)
