Cisco TelePresence SX20 Codec API Reference Guide
Addressing status information with xStatus
To read the status from the system type the root command (xStatus) followed by a path (address expression):
xStatus <address expression>
Example 1: Query all ongoing Call information:
xstatus Call
*s Call 4 Status: Connected
*s Call 4 AnswerState: Answered
*s Call 4 CallPriority: None
*s Call 4 CallType: Video
*s Call 4 CallbackNumber: “sip:name@company.com”
*s Call 4 DeviceType: Endpoint
*s Call 4 Direction: Outgoing
*s Call 4 DisplayName: “Display Name”
*s Call 4 Duration: 9
*s Call 4 Encryption Type: “None”
*s Call 4 FacilityServiceId: 0
*s Call 4 ModifyState: Idle
*s Call 4 PlacedOnHold: False
*s Call 4 Protocol: “sip”
*s Call 4 ReceiveCallRate: 1920
*s Call 4 RemoteNumber: “name@company.com”
*s Call 4 TransmitCallRate: 1920
** end
Example 2: Query the protocol for a call:
xStatus Call Protocol
*s Call 4 Protocol: “sip”
OK
xStatus ?
- Status -
Audio H320 NetworkServices SystemUnit
Call H323 Peripherals Time
Camera HttpFeedback Preset UserInterface
Cameras ICE Provisioning Video
Conference Logging Security
Diagnostics MediaChannels SIP
Experimental Network Standby
OK
Status
A status contains the current state of the codec, such as
connected calls, the status of the gatekeeper registration,
connected inputs and output sources.
Writing xStatus ? on the command line lists all top level
statuses.
Writing xStatus lists all statuses and their current values.
To list out only some of the statuses, write xstatus followed by
the relevant part of the status path.
Contents
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus
