64
——
4. Board information
Single click to select a board and double click to change settings.
5. Conguration display section
View the settings of the selected board.
6. Client condition display
When “Busy” is displayed, operations to search, change settings, and so on are
prohibited.
If you click “Stop”, the “Busy” status is cleared forcibly.
7. Communication timeout
You can congure the time-out duration for searches and other operations.
8. Status log
View the status of the utility.
5.2 Changing Settings
You can congure an Ethernet interface board by selecting it at the main dialog box,
and then clicking “Edit cong”.
These are unalterable parameters.
These parameters are for display purposes only.
To Next Page
