87
——
Print speed
Item Description
Print speed setting CL-E321 2 to 8 inches per second in 1-inch increments (7 to 8 inches per
second possible at normal temperature using a print density of 10
and the recommended media and ribbon)
CL-E331 2 to 6 inch per second in 1-inch increments
Print mode
Item Description
Batch mode Normal printing (single or multiple sheets)
Tear off mode Back-feeds to the tear-off position after printing is complete. (Labels may
peel when roll media is back-fed.)
Cut mode Prints while cutting after every specied number of sheets/labels. Two types
of cut mode operations are available.
Back-feed
Cut-through
(Cut-through pauses printing to cut the previous label when it reaches the
cut position. Printing resumes after the cut operation, but a gap may be
formed at the location where printing was paused.)
Media
Item Description
Media types Roll, fanfold media
(Continuous label media, die-cut media, continuous tag media, and continuous ticket
media)
Roll media orienta-
tion
Outer surface
Recommended
media
Thermal-transfer: Label media (Lintec LR1111)
Direct-thermal media: Label media (Ricoh 150LA-1),
Tag media (Ricoh 130LHB)
Max. media width 118.0 mm / 4.65 inch
Min. media width 25.4 mm / 1.00 inch
Min. label width 21.5 mm / 0.85 inch
Min. media pitch*1 8.89 mm / 0.35 inch*2
Max. media thick-
ness
0.19 mm / 0.0075 inch
Max. media length CL-E321 (Datamax) 2539.7 mm/99.99 inch
(Zebra) 2540.0 mm/100.00 inch
CL-E331 1,270.0 mm / 50.00 inch
Min. media length*1 6.35 mm / 0.25 inch*2
Min. media thickness 0.0635 mm / 0.0025 inch
Loaded roll diameter Max. external diameter: 127 mm / 5 inch
Media core: 25.4 or 38.1 mm / 1 or 1.5 inch
*1 To use media with a pitch of less than 1 inch, enable the [Small Media Adjustment] setting.
*2 For models with a cutter, the cutter operation will not be performed if the media length is less
than 25.4 mm (1 inch).
