Citizen CLP-521 User Manual

25
Printer Operation
Mode Settings
Mode Key operation
HEX dump mode Turning power on while pushing the STOP key.
Self print mode Turning power on while pushing the FEED key.
Menu setting mode Turning power on while pushing the MODE/REPEAT key.
HEX Dump Mode
 When using label media
Turn on printer power while pushing the STOP key. If the PRINT LED has
begun to flash slowly, release the STOP key, and then the printer enters
HEX DUMP mode.
 When using continuous media
Turn on printer power while pushing the STOP key. If the PRINT LED has
stopped flashing slowly and begun to flash rapidly, release the STOP key,
and then the printer enters HEX dump mode.
DUMP LIST
Turning on the power while pressing keys in the following combinations starts
various functions.
Operation Panel (P.14)

Citizen CLP-521 Specifications

General

Print technology	Direct thermal
USB port	No
RS-232 interface	Yes
Optional connectivity	Ethernet
USB 1.1 ports quantity	1
USB 2.0 ports quantity	0
Connectivity technology	Wired
Power requirements	100 - 240V, 50 / 60Hz
Compatible operating systems	Windows 2000/XP
Flash memory	2 MB
Certification	UL, C-UL, FCC: class A, CCC, CE Marking
Internal memory	8 MB
Number of fonts	2
Built-in barcodes	PDF417, UPC-A, UPC-E
Built-in processor	32 Bit RISC
Mean cycles between failures (MCBF)	1000
Core diameter	25.4 mm
Media thickness	0.0635 - 0.254 mm
Maximum label width	104 mm
Maximum label length	812 m
Maximum roll diameter	127 mm
Supported paper width	19.5 - 118 mm

Weight and Dimensions

Depth	289 mm
Width	231 mm
Height	186 mm
