Citizen CLP-521 User Manual

Appendixes
42
Item Description
Printing Printing method Thermal transfer
Resolution Main scanning line density: 203 dots/inch (8 dots/mm)
Sub- scanning line density: 203 dots/inch (8 dots/mm)
Head 864 dots (effective dots: 832 dots)
Max. print width 104 mm 4.1 inch
Max. print length 812.8 mm 32 inch
Print density Print density is adjustable with software
Printing speed Printing speed setting 4, 3 or 2 inches per second.
Print mode Batch mode Normal printing (single or multiple sheets)
Tear off mode Feeds back media to the tear-off position after printing is completed.
Cut mode *1 Prints while cutting at designated sheet units.
The following two kinds of cut mode operations are done.
• Backfeed
• Cut through
(Cut through refers to stopping present printing to cut the previous label
when it reaches the cut position. After cutting, printing restarts but a gap
may be created at the seam of the printing at this time.)
Peel mode*2 Peels labels from the liners after printing them.
Media Types of media Roll, fanfold
(continuous media, die-cuts, continuous tags. paper or tickets)
Kinds of media Thermal-transfer media
Recommended media Heat-transfer media: label media (140LAB Ricoh) tag media (TB2E0V, Mitsubishi Paper)
Max. media width 118.0 mm 4.65 inch
Min. media width 19.5 mm 0.77 inch
Min. label width 19.5 mm 0.77 inch
Min. label pitch 6.35 mm 0.25 inch
Max. media thickness 0.254 mm 0.01 inch
Max. media length 812.8 mm 32 inch
Min. media length 6.35 mm 0.25 inch
Min. media thickness 0.0635 mm 0.0025 inch
On-board roll media Max. external diameter: 127mm 5 inch
diameter Media core: 25.4 to 76mm 1 to 3 inch
Bar code One-dimension • Code3 of 9 • UPC-A • UPC-E • EAN-13 (JAN-13)
• EAN-8 (JAN-8) • Interleaved 2 of 5 • CODE128
• HIBC (Modulus43-used code3 o f9) • CODABAR(NW-7)
• Int2 of 5 (Modulus10-used Interleaved 2 of 5) • Plessey
• CASE CODE • UPC2DIG ADD • UPC5DIG ADD
• Code 93 • Telepen • ZIP • UCC/EAN128
• UCC/EAN128 (for K-MART)
• UCC/EAN128 Random Weight • FIM
Two-dimension UPS Maxi Code, PDF-417, Data Matrix, QRCode
Specifications

Citizen CLP-521 Specifications

General

Print technology	Direct thermal
USB port	No
RS-232 interface	Yes
Optional connectivity	Ethernet
USB 1.1 ports quantity	1
USB 2.0 ports quantity	0
Connectivity technology	Wired
Power requirements	100 - 240V, 50 / 60Hz
Compatible operating systems	Windows 2000/XP
Flash memory	2 MB
Certification	UL, C-UL, FCC: class A, CCC, CE Marking
Internal memory	8 MB
Number of fonts	2
Built-in barcodes	PDF417, UPC-A, UPC-E
Built-in processor	32 Bit RISC
Mean cycles between failures (MCBF)	1000
Core diameter	25.4 mm
Media thickness	0.0635 - 0.254 mm
Maximum label width	104 mm
Maximum label length	812 m
Maximum roll diameter	127 mm
Supported paper width	19.5 - 118 mm

Weight and Dimensions

Depth	289 mm
Width	231 mm
Height	186 mm
