Citizen CLP-521 User Manual

2
Printer Operation
32
Menu Setting Table
Page Setup Menu - allows you to change settings related to the media or print quality.
System Setup Menu - allows you to change settings for the printer hardware and basic control systems.
After Print Menu - changes how the printer reacts after the label has been printed.
Interfaces - changes interface parameters such as baud rate.
Top Menu Sub Menu Default Menu Remarks
*Page Setup Print Speed 4 IPS 2 to 4 IPS Printing speed setting
Print Darkness 10 00 to 30 Print darkness setting (printhead temperature)
Continuous Media 4.00 IN 0.25 to 32.00 IN
Length 101.6mm 6.35 to 812.8mm
Vertical Position 0.00 IN -1.00 to 1.00 IN
0.0mm -25.4 to 25.4mm
Horizontal Shift 0.00 IN -1.00 to 1.00 IN Horizontal printing location adjustment
0.0mm 25.4 to 25.4mm
Media Sensor See Through See Through Label sensor selection
Reflect
None
Small Media OFF ON Setting for small labels
Adjustment OFF
Small Media 1.00 IN 0.25 to 1.00 IN Setting length of small label media
Length 25.4mm 6.35 to 25.4mm
*System Setup Sensor Level 1.5V 0.0V to 3.3V Setting the threshold of the sensor
Buzzer Select ON ON Setting buzzer sounding conditions
OFF
Metric/Inch Inch Inch Setting the units used
mm
Max Media Length 10.00 IN 1.00 to 50.00 IN Setting the maximum label length
254.0mm 25.4 to 1270.0mm
Settings Lock Off On/Off
Keyboard Lock Off On/Off Prevents the control panel from affecting the
printer's conrfiguration. (User "lock-out")
Control Code STD STD/ALT Uses the command instead of STX in DMX
(DMX Mode Only) mode. Sometimes called "AS400 emulation"
Emulation Select DM4 Datamax compatibility selection
DMI DMI DataMax IClass
DM4 DM4 DataMax 430 like
DPP DPP DataMax Prodigy Plus
Menu Setting
Print start position adjustment; the
lower line is in metric mode.
Mode Settings
Setting default length of continuous
media, if selected.
When on, prevents software commands from
changing the values set by the VuePrint menu

Citizen CLP-521 Specifications

General

Print technology	Direct thermal
USB port	No
RS-232 interface	Yes
Optional connectivity	Ethernet
USB 1.1 ports quantity	1
USB 2.0 ports quantity	0
Connectivity technology	Wired
Power requirements	100 - 240V, 50 / 60Hz
Compatible operating systems	Windows 2000/XP
Flash memory	2 MB
Certification	UL, C-UL, FCC: class A, CCC, CE Marking
Internal memory	8 MB
Number of fonts	2
Built-in barcodes	PDF417, UPC-A, UPC-E
Built-in processor	32 Bit RISC
Mean cycles between failures (MCBF)	1000
Core diameter	25.4 mm
Media thickness	0.0635 - 0.254 mm
Maximum label width	104 mm
Maximum label length	812 m
Maximum roll diameter	127 mm
Supported paper width	19.5 - 118 mm

Weight and Dimensions

Depth	289 mm
Width	231 mm
Height	186 mm
