Citizen CT-S310 User Manual

— 9 —
1. GENERAL OUTLINE
The CT-S310 is a thermal line printer designed for use with a broad array of
terminal equipment including, data, POS, and kitchen terminals.
With extensive features, it can be used in a wide range of applications.
1.1 Features
● Low-noise printing.
● Compact design.
● Paper drop-in mechanism facilitating paper handling and head cleaning.
● Can use 80 mm or 58 mm wide paper roll.
● Auto cutter mechanism provided as a standard unit (full cut/partial cut).
● Two types of power supply. Select between built-in power supply type and
AC adapter type.
● The printer allows horizontal, vertical, or wall-mounted (optional) installation.
● Replaceable interface board.(Equipped with USB interface as standard.)
● Built-in cash drawer interface.
● Built-in buzzer.
● A variety of functions selectable with memory switch.
● Registration of user-defined characters and logos into flash memory.
● Barcode & 2D Barcode printing is supported.
(*This feature is available to the printer that prints the firmware version DB1X-
XXXX or upgraded.)
● Page mode. Now you can arrange pages freely.
● 2-color printing is supported.
● Black Mark sensor (Option)

Citizen CT-S310 Specifications

General

Maximum resolution	203 x 203 DPI
RS-232 interface	Yes
Standard interfaces	Serial, USB
USB 1.1 ports quantity	1
Connectivity technology	Wired
Certification	UL, C-UL, FCC Class A, TUV-GS, CE
Internal memory	0.256 MB
Built-in barcodes	Code 39, Code 93
Windows code pages supported	437, 850, 852, 857, 858, 860, 863, 864, 865, 866, Katakana, WPC1252, Thai code 18
Dimensions (WxDxH)	145 x 195 x 159 mm
Power requirements	AC 100-230V, 50/60 Hz, 120VA
AC adapter output voltage	24 V
Compatible operating systems	Windows 2000/XP/Vista/2003 Server, OPOS 1.8, CUPS
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	35 - 85 %
Autocutter durability	1 million cuts
Maximum roll diameter	83 mm
Supported paper width	58, 80 mm

Weight and Dimensions

Depth	195 mm
Width	145 mm
Height	159 mm
