Citizen CT-S310 User Manual

— 25 —
5. OTHER
5.1 External Views and Dimensions
(Unit: millimeter)
Built-in Power Supply Type
AC Adapter Type
195
121
84
145
159
86
145
195
5.2 Manual Setting of Memory Switch
Memory switches can be set manually or by a command.
For manual setting, refer to the next page.
The function of each memory switch is shown in the following table.
(The white-on-black characters are factory setting.)
Switch No. Setting 0 (OFF) 1 (ON)
Memory SW1-1 Power ON Info Valid Not send
SW1-2 Buffer Size 4K bytes 45 bytes
SW1-3 Busy Condition Full/Err Full
SW1-4 Receive Error Print ? No Print
SW1-5 CR mode Ignored LF
SW1-6 Reserved Fixed −
SW1-7 DSR Signal Invalid Valid
SW1-8 Init Signal Invalid Valid
Memory SW2-1 Reserved − Fixed
SW2-2 Auto Cutter Invalid Valid
SW2-3 Spool Print Invalid Valid
SW2-4 Full Col Print LineFeed WaitData
SW2-5 Resume aft PE Next Top
SW2-6 Paper width 80mm 58mm
SW2-7 Reserved Fixed −
SW2-8 PNE Sensor Valid Invalid

Citizen CT-S310 Specifications

General

Maximum resolution	203 x 203 DPI
RS-232 interface	Yes
Standard interfaces	Serial, USB
USB 1.1 ports quantity	1
Connectivity technology	Wired
Certification	UL, C-UL, FCC Class A, TUV-GS, CE
Internal memory	0.256 MB
Built-in barcodes	Code 39, Code 93
Windows code pages supported	437, 850, 852, 857, 858, 860, 863, 864, 865, 866, Katakana, WPC1252, Thai code 18
Dimensions (WxDxH)	145 x 195 x 159 mm
Power requirements	AC 100-230V, 50/60 Hz, 120VA
AC adapter output voltage	24 V
Compatible operating systems	Windows 2000/XP/Vista/2003 Server, OPOS 1.8, CUPS
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	35 - 85 %
Autocutter durability	1 million cuts
Maximum roll diameter	83 mm
Supported paper width	58, 80 mm

Weight and Dimensions

Depth	195 mm
Width	145 mm
Height	159 mm
