Citizen CT-S310 User Manual

— 22 —
4.3 Cleaning the Print Head
1. Tu rn the printer power off.
2. Open the paper cover.
3. Wait several minutes. Wipe off any debris on the heating element of the
head using a cotton swab soaked in ethyl alcohol.
CAUTION!
The print head is hot immediately after printing. Do not touch it with your hand. Do
not touch the heating element of the head with a bare hand or metal object either.
4.4 When the Paper Cover Cannot Be Opened
If the cutter blade remains protruded due to paper jam or for any abnormality,
opening the paper cover may be disabled.
In this case, do not open the paper cover forcibly. Insert a Phillips screwdriver
into the cutter lock releasing feed hole and turn it in the direction of arrow
(clockwise).
Use a #1 screwdriver.
When you find that both ends of the blade reached the lowest position, stop
turning the screwdriver. Open the cover and follow the procedure of removing
jam or other cause of trouble.
Cutter lock releasing feed hole
Phillips screwdriver

Citizen CT-S310 Specifications

General

Maximum resolution	203 x 203 DPI
RS-232 interface	Yes
Standard interfaces	Serial, USB
USB 1.1 ports quantity	1
Connectivity technology	Wired
Certification	UL, C-UL, FCC Class A, TUV-GS, CE
Internal memory	0.256 MB
Built-in barcodes	Code 39, Code 93
Windows code pages supported	437, 850, 852, 857, 858, 860, 863, 864, 865, 866, Katakana, WPC1252, Thai code 18
Dimensions (WxDxH)	145 x 195 x 159 mm
Power requirements	AC 100-230V, 50/60 Hz, 120VA
AC adapter output voltage	24 V
Compatible operating systems	Windows 2000/XP/Vista/2003 Server, OPOS 1.8, CUPS
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	35 - 85 %
Autocutter durability	1 million cuts
Maximum roll diameter	83 mm
Supported paper width	58, 80 mm

Weight and Dimensions

Depth	195 mm
Width	145 mm
Height	159 mm
