25. SPECIFICATIONS
FM Tuner
Frequency Range: 87.9 MHz to 107.9 MHz
Usable Sensitivity: 8 dBµV
50dB Quieting Sensitivity: 14 dBµV
Alternate Channel Selectivity: 70 dB
Stereo Separation: 25dB(100Hz),30dB(1kHz),25dB(10kHz)
Frequency Response: 30 Hz to 14kHz
AM Tuner
Frequency Range: 530 kHz to 1710 kHz
Usable Sensitivity: 30 dBµV
DVD Player System
Digital Versatile Disc System with CDDA capable
Usable discs:
DVD video disc, Compact disc
Frequency Response: 20 Hz to 20 kHz
Sound/Noise Ratio: 95 dbA (1W Ref)
Dynamic Range: 95 dB (1 kHz)
Distortion: 0.05%
Video system: NTSC/PAL
Audio/Video Input
Audio input voltage:
≤
2 Vrms
Video input voltage : 1.0 Vp-p@75
Audio input sensitivity (at 2V output)
High : 325mVrms
Mid : 650mVrms
Low : 1.3Vrms
Audio/Video output
Video output voltage: 1.0Vp-p @75
NX501 Screen Size: 6.2” wide type
Pixels: 1,152,000
Resolution: 800 x 480 x 3 (RGB)
NZ501 Screen Size: 7” wide type
Pixels: 1,152,000
Resolution: 800 x 480 x 3 (RGB)
Bluetooth
Specication: Bluetooth Ver 2.1+EDR
Prole: HFP1.5(Hands Free Profile)
HSP1.0 (Headset Profile)
A2DP (Advanced Audio Distribution Profile)
AVRCP1.2,1.3,1.4 (AV Remote Control Profile)
Power Class: 2
MP3 mode
Bit rate: 32 kbps to 320 kbps
Sampling rate: 32kHz,44.1kHz, 48kHz
WMA mode
Bit rate: 64 kbps to 192 kbps
Sampling rate: 32kHz,44.1kHz, 48kHz
USB
Specication: USB 1.1/2.0 (FS)
Playable audio format:
MP3(.mp3): MPEG 2/Audio Layer-3
WMA(.wma): Ver 7/8/9.1/9.2
Playable Video Format
Disc Video: .mp4 (MPEG4/AAC) 720*480
.avi (MPEG4/MP3) 720*480
.mpg (MPEG2/MP3) 720*480
USB Video: .mp4 (MPEG4/AAC) 480*272
.mp4 (H.264/AAC) 480*272
.3gp (MPEG4/AAC) 480*272
.avi (MPEG4/MP3) 480*272
.mpg (MPEG2/MP3) 480*272
General
Power source voltage:
14.4 VDC (10.8 to 15.6V allowable)
Ground: Negative
Current consumption: 4.0 A @1 W
Auto Antenna Rated Current: 500 mA less
Note:
• Specications comply with JEITA Standards.
• Specications and design are subject to change
without notice for further improvement.

Clarion NX501 Specifications

General

AUX in	Yes
USB version	2.0
Bluetooth profiles	A2DP, AVRCP, DUN, HFP, HSP, OPP, PBAP
Line outputs (RCA)	8
USB ports quantity	1
CD-R playback	-
Audio formats supported	MP3, WMA
Supported radio bands	AM, FM
DIN size	2 DIN
Output power	200 W
Product color	Black
Disc types supported	CD, DVD
Audio output channels	4.0 channels
Maximum power per channel	50 W
Display type	LCD
Display diagonal	6.2 \
Compatible memory cards	MicroSD (TransFlash)
