6. Cautions on Wiring

1. Be sure to turn the power off before wiring.

2. Be particularly careful where you route the wires.

Keep them well away from the engine, and exhaust pipe, etc. Heat may

damage the wires.

3. If the fuse should blow, check to see if the wiring is correct.

If a fuse is blown, replace it with a new one of the same amperage rating as

the original (15A FUSE).

4. To replace the fuse, remove the old fuse on the back of the unit and insert the

new one. (Figure 8)

NOTE:

There are various types of fuse holder. Do not let the battery side touch other metal

parts.

CAUTION

caution

After the connection, fix the cord by a clamp

or insulation tape for protection.

Fuse (15A FUSE)

Fuse holder

Figure 8
