DIMENSIONS
9 - TECHNICAL
INFORMA
TION
(1) WATER INPUT OF EUROKONUS 3/4” EXCHANGER
(2) WATER OUTPUT OF EUROKONUS 3/4” EXCHANGER
(3) CONDENSATE DISCHARGE DUCT
Ø 14 MM
SIZE
3
5
11
15 17
A
mm 737
937
1137
1337
B
mm
131 131 131 131
C
mm
639 639 639 639
Net weight
kg
17 20 23 26
1537
131
639
29
Built-in version - 4
pipes
Cased version - 4
pipes
SIZE
3
5
11
15 17
A
mm 527
727
927
1227
B
mm
126 126 126 126
C
mm
639 639 639 639
Net weight
kg 9
12
15
18
1327
126
639
21
A
B
1
2
3
C
1
2
3
A
B
C
83
82
84
