InteliLite Global Guide
132
DPFAshLoad (page 454)
DPFSootLoad (page 454)
DEF Level (page 454)
Control of After-Treatment regeneration function
User can force or inhibit regeneration process by activating appropriate binary inputs of the controller. Please
see the list of binary inputs below:
FORCE REGENERATION (PAGE 528)
REGENERATION INHIB (PAGE 535)
5.5.23 Alternate configuration
In controller are 3 sets of configuration.
Configuration set 1 Configuration set 2 Configuration set 3
Nominal Power Split Phase 1
(page 333)
Nominal Power 1 (page 333)
Nominal RPM 1 (page 331)
Nominal Frequency 1 (page 331)
Nominal Voltage Ph-N 1 (page
332)
Nominal Voltage Ph-Ph 1 (page
332)
Nominal Current 1 (page 331)
Connection Type 1 (page 329)
ECU Speed Adjustment 1 (page
342)
Nominal Power Split Phase 2
(page 337)
Nominal Power 2 (page 337)
Nominal RPM 2 (page 336)
Nominal Frequency 2 (page 335)
Nominal Voltage Ph-N 2 (page
336)
Nominal Voltage Ph-Ph 2 (page
336)
Nominal Current 2 (page 335)
Connection type 2 (page 333)
ECU Speed Adjustment 2 (page
342)
Nominal Power Split Phase 3
(page 341)
Nominal Power 3 (page 341)
Nominal RPM 3 (page 340)
Nominal Frequency 3 (page 339)
Nominal Voltage Ph-N 3 (page
340)
Nominal Voltage Ph-Ph 3 (page
340)
Nominal Current 3 (page 339)
Connection type 3 (page 337)
ECU Speed Adjustment 3 (page
343)
Configuration sets can be changed via logical binary inputs ALTERNATE CONFIG 2 (PAGE 499) and ALTERNATE
CONFIG 3 (PAGE 499). Configuration set 1 is active when there is no input activated. In case that inputs
ALTERNATE CONFIG 2 (PAGE 499) and ALTERNATE CONFIG 3 (PAGE 499) are active at the same time, the
configuration set 3 is took in account.
ALTERNATE CONFIG 2 (PAGE 499) ALTERNATE CONFIG 3 (PAGE 499) Active configuration set
0 0 1
1 0 2
0 1 3
1 1 3
IMPORTANT: If LBO ECU POWER RELAY (PAGE 570) is used, change of alternate configuration can
be made only in prestart phase. So prestart has to be set up for enough long time.
