InteliLite Global Guide
89
RPM = 0 or any other shutdown
condition
FUEL SOLENOID (PAGE 572) off,
STOP SOLENOID (PAGE 598) on
Shutdown
Start request READY TO LOAD (PAGE 587) on Running
Stop RPM = 0, Oil pressure not detected,
Generator voltage < 10V, D+ not
active
Ready
If at least one of engine running
indication is detected when Stop
Time (page 203) elapsed.
Stop (Stop
fail)
Note: If all generator parameters are OK and Minimal Stabilization Time (page 200) elapsed, indicates that
GCB is possible to close. In AUTO Mode GCB is closed in this moment automatically.
Note: The start-up sequence can be interrupted in any time by stop request
5.5.2 Operating Modes
Selecting the operating mode is done through Left and Right buttons on the front panel or by changing the
Controller mode (page 182) setpoint (from the front panel or remotely).
Note: If this setpoint is configured as password-protected, the correct password must be entered prior to
attempting to change the mode.
Note: The mode cannot be changed if Access Lock input is active.
The following binary inputs can be used to force one respective operating mode independent of the mode
setpoint selection:
Remote OFF (page 536)
Remote MAN (page 536)
Remote AUTO (page 535)
If the respective input is active the controller will change the mode to the respective position according to the
active input. If multiple inputs are active, the mode will be changed according to priorities of the inputs. The
priorities match the order in the list above. If all inputs are deactivated, the mode will return to the original
position given by the setpoint.
OFF
No start of the gen-set is possible. Controller stays in Not ready status and cannot be started any way. The
buttons GCB , Start and Stop including the appropriate binary inputs for external buttons are not
active.
IMPORTANT: When engine is running, it is not possible to switch gen-set to OFF mode.
MAN
The engine can be started and stopped manually using the Start and Stop buttons (or external buttons
wired to the appropriate binary inputs) in MAN mode. When the engine is running, GCB can be closed.
