M0201ANC_uc CommScope Era
™
Fiber Low Power Carrier Access Point Installation Guide
© June 2019 CommScope, Inc. Page 19
Plan and Prepare for a Fiber CAP L Installation
Mounting Dimensions for Two CAP Ls Mounted with the Dual Mounting Kit
325mm
[12.8"]
448mm
[17.64"]
486mm
[19.13"]
454mm
[17.87"]
10mm
[0.394"]
4X
274mm
[10.79"]
538mm
[21.2"]
247mm
[9.72"]
