CommScope CAP MX Series User Manual

CommScope Era
™
Fiber Low Power Carrier Access Point Installation Guide M0201ANC_uc
Page 52 © June 2019 CommScope, Inc.
Mount the Fiber CAP L
Wall Mount a CAP L Using a CAP L Hybrid Fiber Splice Box Kit
1 Attach the Hybrid Fiber Splice Box to the Wall Bracket with the three captive screws already installed in
the Splice Box.
Connect three capve screws on
Hybrid Fiber Splice Box to Wall Bracket
2 Attach the assembled Wall Mounting Bracket and Hybrid Splice Box to the selected mounting location.
3 Use the six M6-1.0 x14mm screws to attach the two Angled Mounting Brackets to
the back of the CAP L,
as shown below.
Six M6-1.0 x 14mm screws
