9.1 Dimensions and weights
Dimensions, Convotherm 4 EB/ES
6.10 6.20 10.10 10.20 12.20 20.10 20.20
Appliance including packaging
Width [mm] 1100 1345 1100 1345 1410 1165 1410
Height [mm] 1010 1010 1280 1280 1615 2150 2150
Depth [mm] 940 1140 940 1140 1170 970 1170
Appliance excluding packaging
Width for appliance with right-hinged
appliance door
[mm] 875 1120 875 1120 1135 890 1135
Width for appliances with disappear‐
ing door inclusive of guide fixing
bracket
[mm] 966 1211 966 1211 1247 1002 1247
Height [mm] 786 786 1058 1058 1406 1942 1942
Depth with appliance door closed [mm] 792 992 792 992 1020 820 1020
Safety clearances
Rear [mm] 50 50 50 50 50 50 50
Right, for appliance with right-hinged
appliance door
[mm] 50 50 50 50 50 50 50
Right, for appliances with disappear‐
ing door
[mm] 50 50 50 50 50 50 50
Left
(larger gap recommended for servic‐
ing)
[mm] 50 50 50 50 50 50 50
Top (for ventilation) [mm] 500 500 500 500 500 500 500
Dimensions, Convotherm 4 GB/GS
6.10 6.20 10.10 10.20 12.20 20.10 20.20
Appliance including packaging
Width [mm] 1100 1345 1100 1345 1410 1165 1410
Height [mm] 1010 1010 1280 1280 1615 2150 2150
Depth [mm] 940 1140 940 1140 1170 970 1170
Appliance excluding packaging
Width for appliance with right-hinged
appliance door
[mm] 875 1120 875 1120 1135 890 1135
Width for appliances with disappear‐
ing door inclusive of guide fixing
bracket
[mm] 966 1211 966 1211 1247 1002 1247
Height [mm] 786 786 1058 1058 1406 1942 1942
Depth with appliance door closed [mm] 792 992 792 992 1020 820 1020
Safety clearances
Rear [mm] 50 50 50 50 50 50 50
Right, for appliance with right-hinged
appliance door
[mm] 50 50 50 50 50 50 50
Right, for appliances with disappear‐
ing door
[mm] 50 50 50 50 50 50 50
Left
(larger gap recommended for servic‐
ing)
[mm] 50 50 50 50 50 50 50
Top (for ventilation) [mm] 1000 1000 1000 1000 1000 1000 1000
9 Technical data
121
