4.2 Moving the appliance to the installation location
Space required for conveying the appliance
Make sure that there is enough width and height along the entire route used for conveying the appli‐
ance to ensure it can get through to its installation location.
The table below shows the dimensions of the appliances including packaging, which are needed to
determine the minimum doorway dimensions required to allow the appliance to be brought to its instal‐
lation location:
6.10 6.20 10.10 10.20 12.20 20.10 20.20
Width
[mm] 1100 1345 1100 1345 1410 1165 1410
Height
[mm] 1010 1010 1280 1280 1615 2150 2150
Depth
[mm] 940 1140 940 1140 1170 970 1170
Load bearing capability for conveying the appliance
Provide moving equipment that is rated capable of carrying the load.
Refer to the weight of the appliances including packaging to determine the minimum working load limit
of handling equipment; see 'Dimensions and weights on page 121'.
Moving the appliance to the installation location
Please observe the following points when conveying the appliance:
■
Always move the appliance on a pallet.
■
Always move the appliance in an upright position.
■
Move the appliance slowly and carefully, and secure it against tipping over.
Make sure that you do not knock against things with the appliance.
Avoid moving appliance along uneven routes or up or down steep slopes.
4 Moving the appliance
45
