9.11 Dissipated heat
Convotherm 4 EB/ES
6.10 6.20 10.10 10.20 12.20 20.10 20.20
Latent heat [kJ/h] 2100 3500 3500 6400 6900 6900 11000
[kW] 0.58 0.97 0.97 1.78 1.92 1.92 3.06
Sensible heat [kJ/h] 2500 4500 4500 7800 7800 8900 14100
[kW] 0.69 1.25 1.25 2.17 2.17 2.47 3.92
Convotherm 4 GB/GS
6.10 6.20 10.10 10.20 12.20 20.10 20.20
Latent heat [kJ/h] 2100 3500 3500 7100 8200 7100 12200
[kW] 0.58 0.97 0.97 1.97 2.28 1.97 3.39
Sensible heat [kJ/h] 2500 4100 4100 7200 11000 11000 15400
[kW] 0.69 1.14 1.14 2.00 3.06 3.06 4.28
9.12 Water connection
Convotherm 4 EB ES GB GS
Water supply (cold only)
Water supply 2 x G 3/4'' fixed connection, optionally including
connecting pipe (min. DN13 / 1/2'')
Flow pressure [kPa] 150 - 600 (1.5 - 6 bar)
Pressure gauge in the water supply
6.10, 6.20, 10.10, 10.20 [kPa] 100 (1 bar)
12.20, 20.10, 20.20 [kPa] 150 (1.5 bar)
Appliance drain
Model 6.10, 6.20, 10.10, 10.20 Fixed connection (recommended) or funnel waste
trap
Model 12.20, 20.10, 20.20 Fixed connection (recommended) or open tank or
channel/gully
Type DN DN 50
9 Technical data
136
