Supplemental Guide – DOC. 8226D TSR-310: Handheld Touch Screen Remote • 37
Project Upload
Click UploadUserProject to upload a custom user project to the TSR-310. A Project
Upload dialog box opens.
Project Upload Dialog Box
NOTE: If the TSR-310 is running in Performance UI mode, uploading a custom user
project switches the TSR-310 into user project mode automatically. For more
information, refer to the Performance UI for TSR-310 Operations Guide (Doc. 8410).
To upload a custom user project:
1. Click Browse, and then navigate to the project .vtz file on the host computer.
2. Select the project .vtz file, and then click Open.
3. Click Load to load the project .vtz file to the TSR-310. The upload progress is
shown in the dialog box.
4. Once the TSR-310 has completed the project upload, click OK.
Click the x button to close the Project Upload dialog box at any time during the upgrade
process. Clicking the
x button before the project file is uploaded to the TSR-310 cancels
the upload.
Save Changes
Click Save Changes to save any changes made to the configuration settings.
Revert
Click Revert to revert the TSR-310 back to the last saved configuration settings.
