D-Link DAP-2660 User Manual
15
Authentication:
Encryption:
Key Type:
Key Size:
Key Index (1~4):
Network Key:
Conrm Key:
Select the wireless authentication method to use here. Options to choose from are Open System, Shared Key, WPA-Personal,
WPA-Enterprise, and 802.1X. After selecting the Shared Key option, the following parameters will be available for conguration.
Shared Key will limit communication to only those devices that share the same WEP settings. If multi-SSID is enabled, this
option is not available.
Select to Enable or Disable wireless
encryption here.
When the encryption option is enabled,
select the key type here. Options to choose
from are HEX and ASCII.
When the encryption option is enabled,
select the key size here. Options to choose
from are 64 Bits and 128 Bits.
Select the key index value used here. The keys 1 to 4 can be selected.
Enter the wireless WEP key in the space provided here. When HEX was selected as the key type, the network key must
consist out of the numbers 0 to 9 and the letters A to F. When ASCII was selected as the key type, the network key can
consist out of any ASCII characters.
Re-enter the wireless WEP key in the space provided. This key must be identical to the network key entered previously.
Shared Key will send a request to the access point and if the key used matches the one congured on the access point, the access point will send a challenge
to the client. The client will then again send a conrmation of the same key back to the access point where the access point will either return a successful or a
denial packet back to the wireless client.
Access Point Mode (2.4GHz) - Shared Key
