D-Link DAP-2660 User Manual

D-Link DAP-2660 User Manual
9
Method 2 - PoE without PoE Switch or Router
1. Connect one end of an Ethernet cable into the Data In port on the PoE base unit and the other end into one port on your switch, router, or computer.
2. Connect one end of an Ethernet cable into the P+Data Out port on the PoE base unit and the other end into the LAN1 (PoE) port on the Access Point.
3. Use the supplied power adapter. Connect the power adapter to the Power In receptor on the PoE adapter.
4. Connect the power cable to the power adapter and then connect the other end into a power outlet.
DAP-2660

D-Link DAP-2660 Specifications

General

2.4 GHz	Yes
Modulation	PSK
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3u
Maximum data transfer rate	1200 Mbit/s
Internal	No
Certification	FCC\\r IC\\r CE\\r UL
Security features	Network access point (NAP)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, SSID, WPA, WPA2
Antenna features	Integrated antenna
Antennas quantity	4
Antenna gain level (max)	4 dBi
Power consumption (typical)	11 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	269 mm
Package width	204 mm
Package height	64 mm
Package weight	562.5 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	2047 mm
Pallet gross weight (air)	439460 g
Quantity per pallet (air)	480 pc(s)
Shipping (inner) case width	290 mm
Shipping (inner) case height	239 mm
Shipping (inner) case length	352 mm
Shipping (inner) case weight	4385 g
Shipping (inner) case net weight	2230 g
Number of cartons per pallet (air)	96 pc(s)
Quantity per shipping (inner) case	5 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	170 mm
Height	28 mm
Weight	316 g
