24
Channel Width:
Captive Prole:
Remote AP MAC
Address:
Site Survey:
Authentication:
Allows you to select the channel width you would like to operate in. Select 20 MHz if you are not using any 802.11n wireless
clients. Auto 20/40 MHz allows you to connect to both 802.11n and 802.11b/g or 802.11a wireless devices on your network.
Select the enable or disable the captive portal feature here.
Enter the MAC addresses of the APs on your network that will serve as bridges to wirelessly connect multiple networks.
Click on the Scan button to search for available wireless networks, then click on the available network that you want to
connect with.
Select the wireless authentication method to use here. In the WDS with AP mode, the following authentication methods are
supported: Open System and WPA-Personal.
For more information about the wireless security, refer to page 14.

D-Link DAP-2660 Specifications

General

2.4 GHz	Yes
Modulation	PSK
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3u
Maximum data transfer rate	1200 Mbit/s
Internal	No
Certification	FCC\\r IC\\r CE\\r UL
Security features	Network access point (NAP)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, SSID, WPA, WPA2
Antenna features	Integrated antenna
Antennas quantity	4
Antenna gain level (max)	4 dBi
Power consumption (typical)	11 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	269 mm
Package width	204 mm
Package height	64 mm
Package weight	562.5 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	2047 mm
Pallet gross weight (air)	439460 g
Quantity per pallet (air)	480 pc(s)
Shipping (inner) case width	290 mm
Shipping (inner) case height	239 mm
Shipping (inner) case length	352 mm
Shipping (inner) case weight	4385 g
Shipping (inner) case net weight	2230 g
Number of cartons per pallet (air)	96 pc(s)
Quantity per shipping (inner) case	5 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	170 mm
Height	28 mm
Weight	316 g
