DGS-1520 Series Gigabit Ethernet Smart Managed Switch Hardware Installation Guide
27
Web User Interface (Web UI)
The Web UI, a graphical representation, provides access to most of the software features available on the Switch.
These features can be enabled, configured, disabled, or monitored using any standard web browser, like Microsoft’s
Internet Explorer, Mozilla Firefox, Google Chrome, or Safari. The MGMT port offers an Out-Of-Band (OOB)
connection to the Web UI and the LAN ports offers an in-band connection to the Web UI using HTTP or HTTPS (SSL).
NOTE: For more information about the Web UI, refer to the DGS-1520 Series Web UI Reference Guide.
Connecting to the Web UI
To access the Web UI, open a standard web browser, enter the IP address of the Switch into the address bar of the
browser, and press the Enter key.
Figure 5-2 IP address in Internet Explorer
NOTE: The default IP address of the switch is 10.90.90.90 (subnet mask 255.0.0.0).
The default username and password is admin.
Logging into the Web UI
In the authentication window, enter the User Name and Password and click the Login button to access the Web UI.
Figure 5-3 Web UI Login Window
NOTE: For security reasons, it is highly recommended to configure a personal username and password
for this Switch.
