DGS-1520 Series Gigabit Ethernet Smart Managed Switch Hardware Installation Guide
35
Appendix B - Cables and Connectors
Ethernet Cable
When connecting the Switch to another switch, a bridge, or hub, a straight-through Category 5/5e/6a/7 cable is
necessary. The following diagrams and tables show the standard RJ45 receptacle/connector and their pin
assignments.
Figure B-1 Standard RJ45 port and connector
RJ45 Pin Assignment:
Contact MDI-X Port MDI-II Port
