D-Link DSL-520B User Manual

4D-Link DSL-520B ADSL2+ Modem User Manual
Section 1 - General Information
General Information
The D-Link DSL-520B is an ADSL2+ modem that oers the convenience of Ethernet connections. This user manual provides a simple and easy-to-
understand format to install and congure your modem.
Package Contents
• ADSL2+Modem
• 12VDC,500mADCCEC-compliantswitchingpoweradapter
• RJ-11telephonecable
• RJ-45Ethernetcable
• QuickInstallGuide
• InstallationCD-ROM
Note: Using a power supply with a dierent voltage rating than the one included with the DSL-520B will cause damage and void the warranty for this product.
Important Safety Instructions
• Placeyourmodemonaatsurfaceclosetothecablesinalocationwithsucientventilation.
• Topreventoverheating,donotobstructtheventilationopeningsofthisequipment.
• Plugthisequipmentintoasurgeprotectortoreducetheriskofdamagefrompowersurgesandlightningstrikes.
• Operatethisequipmentonlyfromanelectricaloutletwiththecorrectpowersourceasindicatedontheadapter.
• Donotopenthecoverofthisequipment.Openingthecoverwillvoidanywarrantiesontheequipment.
• Unplugequipmentrstbeforecleaning.Adampclothcanbeusedtocleantheequipment.Donotuseliquid/aerosolcleanersor
magnetic/static cleaning devices.
• Toreducetheriskofre,useonlyNo.26AWG(orlargerdiameter/smallerAWG)RJ-11telephonecable.

D-Link DSL-520B Specifications

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite downstream	up to 1.5 Mbps
G.lite upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 12 Mbps
ADSL full rate downstream	up to 24 Mbps
ADSL full rate upstream	up to 1 Mbps

Interfaces

ADSL interface	RJ-11 connector
LAN interface	RJ-45 port
Ethernet	10/100BASE-T
